Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens

Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens
Informacion basica
Lugar de origen: PORCELANA
Nombre de la marca: CONWIN
Certificación: CE,ROHS
Cantidad de orden mínima: 1sqm
Contactar ahora
Píxel: 8 mm Garantía: 3 años
Mantenimiento: Servicio delantero Mejor distancia de visión: 1-10 metros
Espesor: 80 mm Método de mantenimiento: Frente
Modo del paquete: SMD2121 Relación: 16: 9
Resaltar:

outdoor LED digital signage display

,

double sided LED billboard screen

,

solar powered outdoor LED display

Product Paramenters
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 0
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 1
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 2
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 3
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 4
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 5
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 6
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 7
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 8
Pixel Pitch (mm)
6.67
8
10
Pixel Configuration
SMD2727
SMD3535
SMD3535
Resolution(dots)
72*48
60*40
48*32
Size (mm)
480*320
480*320
480*320
Size(mm)
960*960*82.6
960*960*82.6
960*960*82.6
Material
Aluminum
Aluminum
Aluminum
Weight(kgs/Panel)
27
26
25
Resolution(dots)
144*144
120*120
96*96
Pixel Density(dots/㎡)
22500
15625
10000
Brightness(nits)
5500(8000nits gold wire optional)
5500(8000nits gold wire optional)
5500(8000nits gold wire optional)
Grey(Bit)
14
14
14
Refresh Rate(Hz)
3840
3840
3840
Color temperature(K)
5500~9500
5500~9500
5500~9500
Scanning
1/5
1/3
1/2
Viewing Angle(H/V)
140°/140°
140°/140°
140°/140°
Max Power(W/㎡)
640
640
640
Avg Power (W/㎡)
190
190
190
AC Input Voltage
AC100--240V±10%/50~60Hz
AC100--240V±10%/50~60Hz
AC100--240V±10%/50~60Hz
Storage TEMP(℃)
-40~60
-40~60
-40~60
Working TEMP (℃)
-30~50
-30~50
-30~50
Storage Humidity (RH)
10%~60% No condensation
10%~60% without condensation
10%~60% without condensation
Working Humidity(RH)
10%~60% No condensation
10%~60% without condensation
10%~60% without condensation
Protection(Front/Back)
IP66
IP66
IP66
Maintenance Types
Front&Rear Maintenance
Front&Rear Maintenance
Front&Rear Maintenance
Life Span(hrs)
≧100000
≧100000
≧100000
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 9
Outdoor LED Screen Solar Electronic Signs Double Sided Billboard Steel Structure External Outdoor Led Digital Signage Display Screens 10
